complied IEC61850 Protection Relay Tester

Brand Name: Kingsine
Model Number: KF86
MOQ: 1 set
Price: Negotiation
Delivery Time: 15 working days
Payment Terms: L/C,T/T
Detail Information
Place of Origin:
China
Certification:
CE/ISO9001
Nominal Voltage:
220V/110V (AC)
Allowable Voltage:
85 - 265 VAC ;127V~350V(DC)
Nominal Frequency:
50Hz
Allowable Frequency:
47-63Hz
Current:
10A Max
Power Consumption:
1200VA Max
Supply Ability:
100 sets/month
Highlight:

IEC 61850 Protection Relay Tester

,

220V Protection Relay Tester

,

IEC 61850 KF86

Product Description

complied IEC61850 Protection Relay Tester



Description Of Synchronize Relay Testing



Relay protection microcomputer test device plays a key role in operating electricity power systems reliably and safely. It is the testing device used in professional field of microcomputer protection, relay protection, excitation measurement, fault recorder.



Feature Of Intelligent Relay Tester



With analog (6x130V voltage, 6x20A current) and IEC61850 SMV messages simultaneously output;
Built-in dual-core CPU industrial computer, built-in large-capacity SSD solid drive; operating system Embedded Windows 7; 9.7-inch true color LCD screen, 1024×768 resolution, touch screen operation. Can work offline or online;
Provide 8 pairs of LC optical ports, can transmission and receive 36 channels of IEC61850-9-1, IEC61850-9-2 frame format sample values; with optical power test function;
Provide 6 ST output optical ports and 2 ST receive optical ports, which can output 6 sets of sampled value messages conforming to IEC60044-7/8 (FT3) format; can receive 2 sets of FT3 format of IEC60044-7/8 specification Sampled value message;
Can subscribe/publish GOOSE information or output, receive switching, and realize closed-loop testing of protection;





Specification Of Overcurrent Relay Test Set



AC current source
Amplitude & Power 6×20A @ 90VA max each;
3×40A @ 180VA max each;
Accuracy ±1mA @ <0.5A
<0.02%Rd+0.01Rg Typ. @ 0.5A~20A
<0.05%Rd+0.02Rg Guar. @ 0.5A~20A
Range Range I: 2A
Range II: 20A
Automatic Range
DC Offset <3mA Typ./ <10mA Guar
Resolution 1mA
Distortion <0.025%Typ. / <0.07% Guar.
Ascends/Descent response <100us
DC Current source
Amplitude & Power 6×10A @ 50W max
Accuracy ±5mA @ <1A
±0.2% @ ≥1A
Ascends/Descent response <100us
AC voltage source
Amplitude & Power 6×130V @ 65VA max each
Accuracy ±2mV @ <2V
<0.015%Rd+0.005Rg Typ. @ 2~130V
<0.04%Rd+0.01Rg Guar. @ 2~130V
Range Range I: 13V
Range II: 130V
Automatic Range
DC Offset <10mV Typ./ <60mV Guar
Resolution 1mV
Distortion <0.015%Typ. / <0.05% Guar.
Ascends/Descent response <100us
DC Voltage source
Amplitude & Power 6×150V @ 75W max
1×300V @ 150W max
Accuracy ±10mV @ <5V
±0.2% @ ≥5V
Ascends/Descent response <100us
Frequency & Phase Angle
Frequency Range DC ~ 1000Hz, 3000Hz transient
Frequency Accuracy ±0.5ppm
Frequency Resolution 0.001Hz
Phase Range -360°~360°
Phase Accuracy <0.02° Typ. / <0.1° Guar. 50/60Hz
Phase Resolution

0.001°





Advantage Of Frequency Relay Test System



Optional modules:IEC61850 functions:

Fully complying IEC61850 Sampling value and GOOSE; (IEC61850-9-1, IEC61850-9-2/(LE), IEC60044-7/8)
Able to simultaneously output sampling value and analog signals, or subscriber and publish GOOSE message and relay contact binary I/O function.
Up to 36 sampling value channels can be mapped.





FAQ



Q: Can the relay protection tester show the impedance curve?

A: Yes.



Q: What is your technical advantages?

A: 10kg, very small size (390mm*256mm*140mm) easy carry on flight journey.6x20A, 6x130V analog output channels.



Q: How long is the warranty period?

A: 3-Years guarantee of free repair and life-long maintenance
