Secondary Injection Test Set
Created with Pixso. Protective IEC61850 K68i Secondary Injection Testing Kit

Protective IEC61850 K68i Secondary Injection Testing Kit

Brand Name: KINGSINE
Model Number: K68i
MOQ: 1 set
Price: Negotiation
Delivery Time: 15 working days
Payment Terms: L/C,T/T
Detail Information
Place of Origin:
China
Certification:
ISO9001,CE
Lightweight:
20.5Kg
Outputs:
4x300V & 3x35A
Dimensions(W X D X H):
360×450×140(mm)
Power Supply:
85~264Vac,45Hz~65Hz
Supply Ability:
50 sets/month
Highlight:

20.5Kg Secondary Injection Testing Kit

,

K68i Secondary Injection Testing Kit

,

IEC61850 K68i

Product Description

Protective K68i 20.5Kg Secondary Injection Testing Kit



Overall design

1 Hardware connection





The field test platform consists of three parts:

  • Client software: mainly completes the display of test content and interaction with users;

  • Interface link library: mainly complete the control and interaction of the tester, issue test parameters, and upload test results;

  • Relay tester: It receives instructions from the interface link library to complete the test content. The first two parts are installed on the same computer.



1.2 System Application Case



  • System Application Case diagram describes the main work methods of field test operator. The field test part needs to interact with the tester to automatically complete the test and obtain the test results. The main interaction mode is provided by the tester interface.



You can see from the figure:



  • The automatic test work is done together by 3 parts of the client, the tester interface link library and the tester;

  • The online experiment flowchart described the test interface main works ways.



Advantage Of Universal Secondary Injection Tester Complying IEC61850

Variable battery simulator, DC 0-300V, 120Watts max.
Quick relay testing facility in Manual mode
Switch on to fault test(SOTF)
GPS sync end-to-end testing
Online Vector display
Automatic test report creation
Anti-clipping detect, Wrong wiring connect alarm and self-protect, overload and overheat protection
